Nebula Node Group v1.2 released

nebulanode_v1.2.0Download .blend file

I’ve now expanded the control you can give to the stars:

  • An input is now provided so you can choose to add your own starfield effects.
  • I’ve moved the stars out into a separate set of “StarsNodes” that you can now use to alter the existing stars.
  • You can now choose to blend the stars more with the color of the nebula to produce a more harmonious effect.

I’ve update the instructions in the .blend file, and any questions let me know. Enjoy!



Filed in Nebulas | Comment Now

Nebula Node Group v1.1 released

nebulanode_v1.1.0Download Nebula Node Group v.1.1.0

I made some small additions to bring better control to the ambient rim lights around the clouds:

Before, you could just get this:

nebulanode_darkbluenebNow, you can have better control to get effects like this:

nebulanode_purplenebI’ve added the full instructions for the node group in the .blend file’s text editor under “Nebula Node Instructions”.

Enjoy!

Filed in Nebulas, Tutorials | 1 Comment

Blender Nebula Group Node: Tutorial & Download

Download .blend file

I thought it would be good to share my work on creating nebula effects in Blender and make an adjustable Blender node called “Nebula” that Blender users can download and create different effects with, seeing as I don’t have much time to create the images myself.

With the “Nebula” node you can produce a range of effects, such as:

nebulanode_blueneb nebulanode_purpleneb1nebulanode_purplenebnebulanode_orangegreenneb3nebulanode_darkredneb

Tutorial

What follows in an overview about how to use the “Nebula” Group Node and a selection of other example .blend files you can download with the group node in it.  I’ve also added for upload some samples from my previous post on the subject.

The tutorial assumes that you have a working knowledge of Blender and how to install a group node in it. If you’re new to Blender, it’s all open source and is definitely worth spending the time learning it.

Here is a screenshot of the Nebula Node in Blender’s Cycles Compositor:

Screen Shot 2017-01-31 at 19.15.40

The node works by overlaying a series of different noise effects to produce the clouds and the stars.  The clouds are produced by overlaying 3 coloured noise layers, and the ambient large “suns” are layered on top.  Finally, the smaller stars are mixed in.

Here is a sample node setup that adds the nebula to the background environment in blender cycles (this is also in the sample .blend files):

Screen Shot 2017-01-31 at 14.13.01

The options for the Nebula Node are as follows:

Vectors

The first set of options define the position of each layer.  They are separated out because the key to producing a good effect is offsetting the vector (position) of the layers:

  • Small Stars Vector: The position of the small background stars.
  • Large Stars Vector: The position of the larger ambient stars.  Note that these aren’t exactly star-like, and more produce the ambient lighting of the nebula.
  • Clouds 1 Vector: position of the first cloud layer.
  • Clouds 2 Vector: position of the second cloud layer.
  • Clouds 3 Vector: position of the third cloud layer.

You will find that offsetting the cloud vectors using Blender’s mapping node will produce different cloud shapes and effects.

Cloud settings

As noted, the key to getting different nebula effects is by adjusting the 3 layers of cloud noise.  Each layer, labelled Cloud 1-3, has the following settings:

  • Color: The individual colour of each cloud layer, mixed in by the rest by the Screen layer effect.
  • Mix: How strongly mixed the cloud layer is with the overall effect (Default: 1.0)
  • Scale: The size of the noise in the cloud layer.
  • Distortion: The distortion effect applied to the cloud layer.
  • Detail: The amount of variation in the cloud texture.  Higher levels do produce more detail, but be careful not to overly distress the cloud effect.
  • Detail distortion: Applies a distortion effect to the detail.

There are then some more global settings you can play with for the clouds:

  • Cloud darkness: How dark a contrast the overall nebula effect is producing.
  • Cloud Dark Start: The position in the noise where the dark parts of the cloud begin.
  • Cloud Light Start: The position in the noise where the light parts of the cloud begin.

Sun and Star settings

The following settings control the intensity and position of the ambient light (suns) and stars.

  • Large Suns Mix: The intensity of the ambient light of the nebula.
  • Small Stars Mix: How much small stars shine through the nebula.
  • Large Sun Scale: The size of the ambient light on the nebula.
  • Large Sun Ramp Pos 1: The position where the light that brightens the nebula starts.
  • Large Sun Ramp Pos 2: The position where the darker part of the ambient light tails off.

…phew! That’s it.

Below are some of the effects you can get using the Nebula Node and the associated .blend file to load into Blender:

nebulanode_blueneb

Download .blend file

Download .blend file

Download .blend file

Download .blend file

Other Nebula Blender files

Finally, here are some .blend files of earlier effects I’ve done using the same principle but not in a group node.  You might find them useful to adjust for your own projects:

mutara_effect1

Download .blend file

redneb1

Download .blend file

horseheadnebula

Download .blend file

And finally…. Any questions, let me know and I will do my best to respond.

Filed in Nebulas, Tutorials | 10 Comments

SOTL Competition 2016: Entry #3

pioneer-finalNow that the calendar has been released, my third and last entry was of the U.S.S. Pioneer – the model won the competition but the shot of it over the Earth was used:

sotl.2016.insignia



Filed in Competitions, SOTL 2016 | 2 Comments

3D nebula effects and clouds on the cloud…

mutara8A screenshot of the final effect, taking seconds to render on a single machine.

I have been experimenting for some time with different ways to produce computer based nebula effects that can be animated, similar to the practical special effect of the Mutara nebula in Star Trek II The Wrath of Khan:

mutara_neb_screenshotall

This was originally achieved by use of a cloud tank, where coloured dyes and other chemicals were immersed in a big glass tank of water, lit from various directions, and then photographed. This effect was used in a number of other 70s/80s films, including Indiana Jones. You can read all about it here, and there are lots of videos like this one that show you how to create your own.

An example of a cloud tank.

In the absence of a large cloud tank, I wanted to look into how to re-create this effect in 3D CGI, where you could build a cloud-like structure you could navigate around – not just a photoshop painting.  Some years ago I looked at Blender’s fledgling volumetric model which showed promise. I tried recreating the tank as a 3D shape, such as a sphere, and then used 3D noise textures to influence the varying density of the cloud inside the sphere.  I then lit it with different coloured lights from various directions and achieved this:

My first attempt.

At that time, you could not increase the detail beyond a certain limit, and the rendering time was quite cumbersome on a single machine (remember in 2009 public distributed computing like Amazon Web Services were still in their infancy).

I revisited the problem a number of years later in 2014.  Blender had developed its Cycles system to include volume rendering, and with their nodes editor I was able to create more effects.  This time I used a more straightforward cube shape and then used 3D noise and colour ramps to control the effects. I also started embedding light sources inside the cube to suggest stars which also produced some better effects.

Here are a selection of an early set of attempts, roughly in chronological order, where I did a lot more close-up shots.  Remember these images are rather raw and have not had any further post-processing. Click for larger versions:


I still found drawbacks to this technique; I had a lot more power to control the effect, but rendering times were still extremely high especially on a single machine.  I was experiencing times of between 1 and 6 hours for a half decent single frame render.

I therefore did one further experiment with this technique using an open source tool called Brenda and ran the process across multiple machines using Amazon Web Services.  This way I could split the work up across multiple machines running simultaneously to reduce the time to render.

mutara_effect_volume_aws

This nebula exists in 3D space and could be navigated in and around with a camera. This image was achieved in 40 minutes, using 8 multi-core machines in parallel – if I had ran it on a single work station, it would have taken nearly 6 hours…

I was still very impatient; Therefore I developed a system that can produce very effective results in a matter of seconds, at the sacrifice of being totally navigable – however you could simulate this using various techniques that splits the clouds up onto multiple 3D planes.

The effect was a development of a photoshop tutorial I saw online.  This tutorial used more traditional painting techniques to great effect, and the key was how the artist overlaid different painted clouds over each others using the colour dodge filter.  The most time consuming part was producing the clouds – so I cut that time down by using a noise texture.

I used Cycles in Blender and the node editor to overlay different noise-generated cloud effects on top of each other using the Screen filter, adding this to the world background.  Because I wasn’t using volumetric rendering any more, I could produce good effects in near-realtime on a single workstation.

Here are some high resolution quality images which all took under a minute to render. Click to enlarge:

mutara9 mutara10 mutara11 mutara12 mutara13 mutara14a mutara15 mutara16 mutara8 mutara7 mutara6

The properties can also be animated, and although you can’t quite navigate around them in the same way as using volumetric materials, the rendering time is significantly reduced – the following HD animation took 15 minutes to render on a single machine, so this effect would take even less across multiple machines. Note that the clouds move half-way through:

You can also create different effects other than the pink/purple mutara nebula effect.  You could create an Eagle nebula like effect like this:

eagle1…or a very red nebula like this:

redneb1So in conclusion I spent a great deal of time working out how to do efficient nebula effects on the fly.  If you happen to use any of the techniques developed here…please give me a mention :)

Filed in Nebulas, Tutorials | 1 Comment

SOTL Competition 2016: Entry #2

uss_yorktown_mark_kingsnorth_50My second entry was of the U.S.S. Yorktown – an old 3D model very close on concept to the Ascension Class, I pulled her out of mothballs and added some detail.

Filed in Competitions, SOTL 2016 | Comment Now

SOTL Competition 2016: Entry #1

Along with the winning entry, I also entered a few others – here was the first:

uss_carolina_mark_kingsnorth_50The background was the start of some nebula-like experiments I’ve been doing using Blender’s volumetrics and noise textures, which I’ll post about later.  Here’s a taster of one of the latest effects:

mutara5

mutara6

Filed in Competitions, Hawking Class, Nebulas, SOTL 2016 | Comment Now

Ships of the Line 2016: Winning Entry

sotl.2016.insigniaI thought it safe to wait until it was announced elsewhere, but I’m happy to report my entry for the Ships of the Line design contest last year made the winning list for the 2016 calendar.

Along with my winning entry, I also entered some others; I’ll start posting those on the website soon.

Filed in Competitions, Insignia Class, SOTL 2016, Starships | 3 Comments

Jupiter Approach and the ships that made it



jup_ship_small

After the Mars Picture, I have made more use of the modelling tools and compositing in Blender to create the above image.  Because you can’t see all of the models in detail though, here are some individual renders of them:

fighter1 fighter2 fighter3 fighter4For the fighter, I was able to quickly texture by using smart UV unwrapping combined with a layered brick-like texture to get the overall effect (the plane was originally intended only for the background and so didn’t need much detail).  However I was impressed with how it came out so I could do more close-up renders and perhaps re-use it later.

Here is the larger ship, slightly inspired by the Sulaco in Alien:

ship1

Note again in Blender I was able to very easily add some aft-boosters using the Emission material.

ship3 ship4Once more I am really enjoying Blender, mainly due to the wealth of tutorials out there, and after the initial learning curve it is incredible easy to model, texture, and composite all within the same application.  Admittedly, the final image had some final colour alterations and highlights added in photoshop, but overall everything was accomplished all in the same program.

Filed in Original Work | 1 Comment

A Mars Odyssey in Blender

mars_odysseyFurthering my work in Blender, I came across some useful tutorials by Dan Brown including how to model panels on smooth surfaces.  I combined this by modelling a planet atmosphere in Blender (a little old, but can be still be done for the latest Blender version) to create a slightly 2001-inspired space scene.

I also recreated my Avalon Station in Blender, very roughly:

station_profile

I then learned a little more about UV mapping in Blender and to put together a space plane, following this tutorial to get the after burner effect:shuttle_profile1shuttle_profile3

shuttle_profile4


shuttle_profile2This was all done using Blender’s Cycles node based texturer and renderer, which I’m very impressed with…hope you think this is an improvement on my last effort!

Filed in Original Work | 1 Comment
